Plumbing Valves Stängventiler Kulventiler Tappvatten

Ball Valve BA 3450S M26x1.5 Dezincification Resistant Brass Beulco

Ball valve BA3450S DN15 without solder connection with high spindle height dezincification resistant brass, stainless steel ball.

Ball Valve BA 3450S M26x1.5 Dezincification Resistant Brass Beulco

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

Ball Valve BA 3450S M26x1.5 Dezincification Resistant Brass Beulco

Ball valve BA3450S DN15 without solder connection with high spindle height dezincification resistant brass, stainless steel ball.

Description

Ball valve BA3450S DN15 without solder connection with high spindle height dezincification resistant brass, stainless steel ball.

Technical Information

  • Dimension: M26x1.5
  • Size: L=55mm
  • Pressure/Flow/Temp: PN16
  • Function: replacement of Securex cone valve
  • Design: external thread
  • Material housing/casing/body: Brass
  • Material quality: Dezincification resistant brass (DZR)
  • Surface protection housing/casing/body: None
  • Dimension connection 1: DN15
  • External pipe diameter connection 1: 15mm
  • Connection 1: External thread M, metric
  • With coupling connection 1: No
  • Dimension connection 2: DN15
  • External pipe diameter connection 2: 15mm
  • Connection 2: External thread M, metric
  • Sealing: PTFE (polytetrafluoroethylene)
  • Pressure class: PN16
  • Max. differential pressure at 20°C: 16bar
  • Media temperature (continuous): -10 - 100 °C
  • Operation: Handle/Lever
  • Model/Version: Straight

Specification

  • Colour: Yellow
  • Material: Dezincification-resistant brass
  • Ball material: Brass
  • Ball surface protection: Chrome-plated
  • Spindle material: Brass
  • Ball seal material: PTFE (polytetrafluoroethylene)
  • Spindle seal material, primary: PTFE (polytetrafluoroethylene)
  • Spindle seal material, secondary: PTFE (polytetrafluoroethylene)
