Plumbing Pipes & fittings Pexrör & Kopplingar LK Golvvärme Golvvärmerör, Pex & LK

LK Underfloor Heating Pipe PE-Xa 8x1.0mm White

PE-Xa pipe with oxygen diffusion barrier for underfloor heating systems, max operating pressure 6 bar (applies to 12 x 2.0).

LK Underfloor Heating Pipe PE-Xa 8x1.0mm White

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

LK Underfloor Heating Pipe PE-Xa 8x1.0mm White

PE-Xa pipe with oxygen diffusion barrier for underfloor heating systems, max operating pressure 6 bar (applies to 12 x 2.0).

Description

PE-Xa pipe with oxygen diffusion barrier for underfloor heating systems. Max operating pressure 6 bar (applies to 12 x 2.0). Max continuous operating temperature 70 ºC (short-term load 95 ºC). Pipe dim 12 x 2.0 pipe distance c/c 150 mm, approx. 7 m/m².

Specifications

  • Dimension: 8x1.0mm
  • Pressure/Flow/Temp: PN6, max temp +60°C (+70°C)
  • Function: For underfloor heating
  • Version: With diffusion barrier
  • Color: White
  • Material: PE-RT
  • Material quality inner layer: PE-Xa
  • Material quality middle layer: EVOH
  • Material quality outer layer: PE-Xa
  • Number of layers: 5
  • Fiberglass reinforced: No
  • Diffusion barrier: Yes
  • External pipe diameter: 8 mm
  • Wall thickness/Material thickness: 1 mm
  • System-bound: Yes
  • Max. media temperature (instantaneous): 95 °C
  • Max. working pressure at 20°C (PN): 6 bar
  • Wall roughness: 0.0005 mm
  • Coefficient of linear expansion: 12 mm/(m.K)
  • Flexible: Yes
  • Suitable for surface mounting: No
  • Minimum bending radius: 40 mm
  • Tube color: White
  • With protective tube: No
  • With electric heating cable: No
  • With thermal insulation: No
  • With protective cap/plug: No
