LK Wall Bracket Grip V2

Wall bracket for pipe outlet from wall or floor. Intended for 25 mm protective pipe and 16 mm media pipe.

LK Wall Bracket Grip V2

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

LK Wall Bracket Grip V2

Wall bracket for pipe outlet from wall or floor. Intended for 25 mm protective pipe and 16 mm media pipe.

Description

Wall bracket for pipe outlet from wall or floor. Intended for 25 mm protective pipe and 16 mm media pipe. Minimum 55 mm free space in the wall is required to install the product. The wall bracket can be attached to, LK Wall Rail with 30 mm hole or short section, drill a 32 mm hole or on the side of the stud, two wall bracket can also be mounted on the side of each other with 40 c/c between the pipe outlets. For installation with 60 c/c turn the LK Wall Rail.

When using LK Wall Bracket Grip V2 for LK PAL Universal Pipe A with empty pipe (RiR), LK Bending Spring INV must be used. Suitable screw for mounting in short section is 4 pcs 4.2x19 not countersunk. Suitable screw for mounting on 2 st 5x60 studs not countersunk. Screws not included. The product has an international design registration.

  • Also for side mounting
  • Compact construction dimensions
  • Stable attachment with three locks in wall rail

Specifications

  • Dimension: 25 mm
  • Function: For wall rail or Kortling
  • Color: Black
  • Material: Plastic
  • Model/Version: Single
  • Suitable for Pipe diameter: 16–20 mm
  • Outer diameter protective tube: 25 mm
  • Center distance: 40–160 mm
  • Material: Plastic
  • Material quality: Other
  • Surface protection: Untreated
  • Color: Other
  • With protective tube locking: Yes
  • Suitable as floor trestle fixture: Yes
  • Suitable as wall trestle fixture: Yes
  • Type of attachment: Snap-on mounting
