Water Heater Eminent CU 35 Nibe

Nibe Eminent 35, you can take a quick shower and still have water for the sink. Can be mounted vertically or horizontally. [Energiklass C]

Water Heater Eminent CU 35 Nibe

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

Water Heater Eminent CU 35 Nibe

Nibe Eminent 35, you can take a quick shower and still have water for the sink. Can be mounted vertically or horizontally. [Energiklass C]

Description

Nibe Eminent 35, you can take a quick shower and still have water for the sink. Nibe Eminent can be installed hanging vertically on the included bracket with the connections downwards, or lying horizontally. The water heater is equipped with a cord and plug for easy connection to a 230 V grounded outlet (gives power 1 kW). Can also be connected to 400 V 2-phase (gives power 3 kW). The higher the power, the faster the recharge. Equipped with a complete valve equipment, consisting of a mixing valve, shut-off/return valve, safety valve with drain function. The thermostat is adjustable up to 80 °C.

Specifications

  • Available corrosion protection Copper
  • Heat content at 80 °C 2.4 kWh
  • Heat time to 80 °C at 3 kW 1.0 hours
  • Power * 1.0 kW at 230 V 1-phase 3.0 kW at 400 V 2-phase
  • Volume 35 liters
  • Connection (cold water / hot water) 15mm
  • Material tank boiler/heater: Copper
  • Volume vessel/tank: 35 l
  • Design: Hanging
  • Connection to hot water pipe: No
  • Suitable for boiling water: No
  • 3-phase design: No
  • Connection cold water tap: Pipe end
  • Connection hot water tap: Pipe end
  • Connection voltage: 230 - 400 V
  • Drainage dimension: Conn. 15 (1/2")
  • Duo version: No
  • Energy efficiency water heating (Nwh): 33.7 %
  • Energy efficiency class: C
  • Frequency: 50 Hz
  • Capacity profile: S
  • Protection class (IP): IP24
  • KIWA certified: No
  • Low pressure version: No
  • Rated power: 3 kW
  • Outer casing material: Steel
  • Max. working pressure: 10 bar
  • Max. permissible working pressure: 10 bar
  • With circulation connection: No
  • With tap/mixer: No
  • With night-time switch: No
  • With cleaning opening: No
  • With protective anode: No
  • With temperature limitation: Yes
  • With temperature indication: No
  • With thermometer: No
  • With pressure reducing valve: No
  • With water cooler: No
  • Positioning of solar panels, horizontal: No
  • Vertical: Yes
  • Heating time from 10°C – 65°C: 45 min
  • External pipe diameter drain/drainage: 15 mm
  • External pipe diameter cold water tap: 15 mm
  • External pipe diameter hot water tap: 15 mm
  • Wall installation: Yes
  • Water heater on plinth: No
  • Vertical placement: Yes
  • Width: 467 mm
  • Depth: 455 mm
  • Height: 565 mm

Note! When purchasing and installing Nibes products in Sweden, you are covered by their warranty. The warranty is only valid in Sweden.
