LK Heating Pipe PE-Xa RiR 50m 25x2.3mm Hollow Pipe 34mm

Description

LK Heating Pipe PE-Xa RiR 25x2.3 mm is delivered complete in a 34 mm protective pipe and is an ideal solution for modern heating installations in various types of properties. The pre-assembled pipe-in-pipe system works excellently as a supply line to LK Heating Circuit Distributors and connects the heat source to the rest of the system safely.

Construction and leakage protection

By placing the heating pipe in an outer casing of hollow pipes, an additional safety barrier against possible water leaks is created. This construction protects the building structure and at the same time makes it easy to inspect or replace the inner pipe if necessary in the future. The roll length of 50 meters allows for long runs without joints, which reduces the risk of future leakage points.

Material properties and capacity

Made of high-quality polyethylene (PE-Xa), this heating pipe offers high thermal stability and good flexibility during installation. The system is designed for a continuous operating pressure of up to 6 bar and can withstand a constant operating temperature of 70 ºC, with the ability to handle temporary temperature peaks of up to 95 ºC.

Technical specifications

• Media pipe: PE-Xa (polyethylene)
• Media pipe dimensions: 25 x 2.3 mm
• Outer diameter of empty pipe: 34 mm
• Delivery form: 50 meter roll
• Maximum operating pressure: 6 bar
• Maximum continuous temperature: 70 ºC (temporary load up to 95 ºC)
• System compatibility: Suitable as a supply line for LK Heating circuit distributors and heating systems
