LK Wall Box UNI Double AX16xG15

For pipe outlet from wall with variable c/c distance from 150-160 mm, Delivered with c/c 150 mm but is easily adjustable to c/c 160 mm.

LK Wall Box UNI Double AX16xG15
Save 18 %
Lagerrensning

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

LK Wall Box UNI Double AX16xG15

For pipe outlet from wall with variable c/c distance from 150-160 mm, Delivered with c/c 150 mm but is easily adjustable to c/c 160 mm.

Description

For pipe outlet from wall with variable c/c distance from 150-160 mm. Delivered with c/c 150 mm but is easily adjustable to c/c 160 mm. Distance between the boxes in wall with waterproofing for tap water or heating pipes should be at least 60 mm. Min. 45 mm space in wall. The neck of the wall box has a diameter of 54 mm.

Use LK Connection Fittings RSK 1881845, 1881847, 1881848, 1881849, 1881850, 1881851, 1881852, 1881853, 1881854 or 1881855 for connection to mixers and taps.

Approved with 16 mm LK PE-X Universal Pipe according to NT VVS 129. For the 16 mm box there are both options with a compression ring connection or a PressPex connection. For the 20 mm box there is only a compression ring connection. Please note that connection with 20 mm PE-X and 16 mm and 20 mm PAL Universal Pipe does not meet the requirements in NT VVS 129 regarding inspection and interchangeability. For more information, see the installation instructions.

Specifications

  • Dimension: 16/25mm x G15
  • Size: c/c150-160mm
  • Function: For pipe outlet from wall
  • Design: Double, press
  • Color: Violet
  • Material: Plastic
  • Model/Design: Double
  • Suitable for embedding in concrete: No
  • Suitable for stud wall: Yes
  • Material housing/enclosure/frame: ABS (acrylonitrile butadiene styrene)
  • Outer diameter protective tube: 25 mm
  • With coupling: Yes
  • Material coupling: Brass
  • Material quality coupling: Dezincification resistant brass (DZR)
  • Outer pipe diameter connection 1: 16 mm
  • Connection 1: Press sleeve
  • Dimension connection 2: Conn. 15 (1/2")
  • Connection 2: Internal thread G, cylindrical (ISO 228-1)
  • System-bound: Yes
  • With mounting plate: Yes
  • Center distance of boxes: 150/160 mm
