Metro Therm Modul 200R Water Heater

Description

Metro Therm Modul 200 R is a high-performance water heater in a stylish and installation-friendly 60x60 module format. With a generous volume of approximately 200 liters, it ensures hot water comfort for the whole family - perfect for easily filling a deep bathtub or taking several long showers in a row without unpleasant cold showers. Thanks to the powerful immersion heater, the water heater recovers very quickly.

Designed for a long service life and specific water conditions

The internal pressure vessel is made of high-quality stainless steel. This provides extremely strong and maintenance-free corrosion protection without the need for an anode, while keeping the net weight significantly lower than enameled counterparts. This stainless steel model is the absolute best choice for those who have:

• Low pH value (acidic water)
• Carbonated water
• Water with a low chloride content

Important information about your water quality: Do you have hard water or water with a high chloride content (e.g. your own well near the sea)? Then you should not choose a stainless steel water heater. For these types of water, we instead recommend an enameled model from the Metro Therm Modul series for optimal service life.

Easy installation for the installer – peace of mind for you

The Metro Therm Modul 200 R is as much a favorite with homeowners for its operational reliability as it is with HVAC installers for its spacious and easily accessible connection space. The heater is delivered complete with a factory-fitted fitting kit containing a safety valve, mixing valve and shut-off valve. The adjustable feet also ensure that the unit stands completely steady even on uneven basement or laundry room floors.

Flexible power and fast recovery

The heater offers flexible electrical connection to suit the conditions of your home. For maximum performance, the connection cable for fixed installation is adapted to 2-phase (3 kW at 400V), which provides a lightning-fast heating time to 50° in only about 184 minutes. If it suits your home better, it can also be connected to 1-phase with a standard plug (1 kW at 230V).

Specifications

• Type name / Model: Type 2002R (Module 200 R)
• Volume: 198 liters
• Corrosion protection: Stainless steel
• Dimensions (HxWxD): 1450x595x615mm (Fits standard 60x60 niches)
• Power and electrical connection: 3 kW (400V 2-phase fixed installation) / 1 kW (230V 1-phase with plug)
• Heating time to 50° at 400V: Approx. 184 minutes
• Capacity: Approx. 7 3-minute showers (or 2–3 10-minute showers in a row)
• Thermostat: Traditional mechanical thermostat
• Pipe connection: Downward (Diameter 22 mm / C-C 150 mm)
• Protection class: IP24 (Approved for wet areas)
• Rated pressure / Max safety pressure: 10 bar / 13 bar
