LK Wall Box UNI Push AX16 V3

LK wall box for AX16 pipes with push connection and G15 thread. For reinforced, easy installation in stud walls or concrete.

LK Wall Box UNI Push AX16 V3

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

LK Wall Box UNI Push AX16 V3

LK wall box for AX16 pipes with push connection and G15 thread. For reinforced, easy installation in stud walls or concrete.

Description

For pipe outlet from wall with min. 45 mm space in wall. The box has been reinforced and updated to be better mounted on the back and side of the wall. The neck of the wall box has a diameter of 53 mm. Screws for mounting the product are included. The minimum c/c distance between pipe outlets is 80 mm. The distance between the boxes in walls with a waterproof layer for tap water or heating pipes should be at least 60 mm.

Use LK Connection Fittings 1881845, 1881847, 1881848, 1881849, 1881850, 1881851, 1881852, 1881853, 1881854 or 1881855 for connection to mixers and taps. Approved with 16 mm LK PE-X Universal Pipe according to NT VVS 129. Please note that connection with LK PAL Universal Pipe does not meet the requirements in NT VVS 129 regarding inspection and interchangeability.

Specifications

  • Dimension: 16/25mm x G15
  • Coupling type: AX16 x G15 PushFit
  • Size: c/c 57mm (minimum)
  • Function: For pipe outlet from wall
  • Design: Complete with support sleeve
  • Color: Gray/transparent
  • Material: Plastic
  • Model/Design: Simple
  • Suitable for embedding in concrete: Yes
  • Suitable for stud wall: Yes
  • Material housing/enclosure/frame: PP (polypropylene)
  • Outer diameter protective tube: 25 mm
  • With coupling: Yes
  • Material coupling: Brass
  • Material quality coupling: Dezincification resistant brass (DZR)
  • Outer pipe diameter connection 1: 16 mm
  • Connection 1: Push-in (Push-coupling)
  • Dimension connection 2: Conn. 15 (1/2")
  • Connection 2: Internal thread G, cylindrical (ISO 228-1)
  • Outer diameter neck: 53 mm
  • System-related: Yes
  • With mounting plate: No
